IXTP60N10T
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 100V 60A TO-220
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $1.913296
≥100 USD $1.574232
≥500 USD $1.332038
≥1000 USD $1.130219
≥3000 USD $1.073706
Inventory: 393
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 500 mJ
Drain to Source Breakdown Voltage 100V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 60A
Turn-Off Delay Time 43 ns
Fall Time (Typ) 37 ns
Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 40 ns
Gate Charge (Qg) (Max) @ Vgs 49nC @ 10V
Current - Continuous Drain (Id) @ 25°C 60A Tc
Input Capacitance (Ciss) (Max) @ Vds 2650pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Rds On (Max) @ Id, Vgs 18m Ω @ 25A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Power Dissipation 176W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 176W Tc
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Additional Feature AVALANCHE RATED
Terminal Finish Matte Tin (Sn)
Resistance 18MOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series TrenchMV?
Published 2008
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 24 Weeks
