IXTM11N80
RoHS
RoHS compliant
RoHS compliantPackage TO-204AA, TO-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
POWER MOSFET TO-3
PDF
/
Inventory: 3687
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
DS Breakdown Voltage-Min 800V
Pulsed Drain Current-Max (IDM) 44A
Drain-source On Resistance-Max 0.95Ohm
Drain Current-Max (Abs) (ID) 11A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 800V
Gate Charge (Qg) (Max) @ Vgs 170nC @ 10V
Current - Continuous Drain (Id) @ 25°C 11A Tc
Input Capacitance (Ciss) (Max) @ Vds 4500pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Rds On (Max) @ Id, Vgs 950m Ω @ 5.5A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 300W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-MBFM-P2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position BOTTOM
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series GigaMOS?
Published 2012
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-204AA, TO-3
Mounting Type Through Hole
