IXTH3N120
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 1200V 3A TO-247
PDF
/
Buying Options
Total Price: USD $14.25
Unit Price: USD $14.245074
≥1 USD $14.245074
≥10 USD $13.438747
≥100 USD $12.678063
≥500 USD $11.960437
≥1000 USD $11.283426
Inventory: 1089
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2003
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature AVALANCHE RATED
Technology MOSFET (Metal Oxide)
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 200W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 150W
Case Connection DRAIN
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 4.5 Ω @ 500mA, 10V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1300pF @ 25V
Current - Continuous Drain (Id) @ 25°C 3A Tc
Gate Charge (Qg) (Max) @ Vgs 39nC @ 10V
Rise Time 15 ns
Drain to Source Voltage (Vdss) 1200V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 18 ns
Turn-Off Delay Time 32 ns
Continuous Drain Current (ID) 3A
JEDEC-95 Code TO-247AD
Gate to Source Voltage (Vgs) 20V
Drain Current-Max (Abs) (ID) 3A
Drain to Source Breakdown Voltage 1.2kV
Pulsed Drain Current-Max (IDM) 12A
Avalanche Energy Rating (Eas) 700 mJ
Compliance
RoHS Status ROHS3 Compliant
