IXTA270N04T4

IXYS
RoHS
RoHS RoHS compliant
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description MOSFET N-CH 40V 270A
PDF
/
Inventory: 8665
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 28 Weeks

Physical

Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB

Technical

Operating Temperature -55°C~175°C TJ
Packaging Tube
Published 2016
Series TrenchT4?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Reach Compliance Code unknown
Power Dissipation-Max 375W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 2.2m Ω @ 50A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 9140pF @ 25V
Current - Continuous Drain (Id) @ 25°C 270A Tc
Gate Charge (Qg) (Max) @ Vgs 182nC @ 10V
Drain to Source Voltage (Vdss) 40V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±15V

Compliance

RoHS Status ROHS3 Compliant
