IXTA15P15T
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 150V 15A TO-263
PDF
/
Inventory: 5745
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Drain to Source Voltage (Vdss) 150V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±15V
Continuous Drain Current (ID) 15A
JEDEC-95 Code TO-263AA
Drain-source On Resistance-Max 0.24Ohm
Pulsed Drain Current-Max (IDM) 45A
DS Breakdown Voltage-Min 150V
Avalanche Energy Rating (Eas) 300 mJ
Gate Charge (Qg) (Max) @ Vgs 48nC @ 10V
Current - Continuous Drain (Id) @ 25°C 15A Tc
Input Capacitance (Ciss) (Max) @ Vds 3650pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Rds On (Max) @ Id, Vgs 240m Ω @ 7A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 150W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Reach Compliance Code not_compliant
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Subcategory Other Transistors
Additional Feature AVALANCHE RATED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series TrenchP?
Published 2013
Packaging Tube
Operating Temperature -55°C~150°C TJ
Compliance
RoHS Status ROHS3 Compliant
Physical
Transistor Element Material SILICON
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
