IXFY4N85X

IXYS
RoHS
RoHS RoHS compliant
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description MOSFET N-CH 850V 3.5A TO252
PDF
/
Buying Options
Total Price: USD $3.44
Unit Price: USD $3.4408
≥1 USD $3.4408
≥10 USD $2.88552
≥100 USD $2.334464
≥500 USD $2.075093
≥1000 USD $1.776808
≥3000 USD $1.673047
Inventory: 127
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Vgs (Max) ±30V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 850V
Gate Charge (Qg) (Max) @ Vgs 7nC @ 10V
Current - Continuous Drain (Id) @ 25°C 3.5A Tc
Input Capacitance (Ciss) (Max) @ Vds 247pF @ 25V
Vgs(th) (Max) @ Id 5.5V @ 250μA
Rds On (Max) @ Id, Vgs 2.5 Ω @ 2A, 10V
FET Type N-Channel
Power Dissipation-Max 150W Tc
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series HiPerFET?
Published 2016
Packaging Tube
Operating Temperature -55°C~150°C TJ

Physical

Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 19 Weeks
