IXFT120N15P
RoHS
RoHS compliant
RoHS compliantPackage TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 150V 120A 3-Pin(2+Tab) TO-268
PDF
/
Inventory: 2938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 2000 mJ
Pulsed Drain Current-Max (IDM) 260A
Drain to Source Breakdown Voltage 150V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 120A
Turn-Off Delay Time 85 ns
Fall Time (Typ) 26 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 42 ns
Gate Charge (Qg) (Max) @ Vgs 150nC @ 10V
Current - Continuous Drain (Id) @ 25°C 120A Tc
Input Capacitance (Ciss) (Max) @ Vds 4900pF @ 25V
Vgs(th) (Max) @ Id 5V @ 4mA
Rds On (Max) @ Id, Vgs 16m Ω @ 500mA, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Power Dissipation 600W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 600W Tc
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE ENERGY RATED
Terminal Finish Pure Tin (Sn)
Resistance 16MOhm
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PolarHT? HiPerFET?
Published 2006
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-268-3, D3Pak (2 Leads + Tab), TO-268AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
