IXFN150N10
RoHS
/
Package SOT-227-4, miniBLOC
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 100V 150A SOT-227
PDF
/
Inventory: 1588
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case SOT-227-4, miniBLOC
Number of Pins 4
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2000
Series HiPerFET?
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Resistance 12mOhm
Terminal Finish Nickel (Ni)
Additional Feature AVALANCHE RATED
Subcategory FET General Purpose Power
Voltage - Rated DC 100V
Technology MOSFET (Metal Oxide)
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Current Rating 150A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max 520W Tc
Operating Mode ENHANCEMENT MODE
Power Dissipation 520W
Case Connection DRAIN
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 12m Ω @ 75A, 10V
Vgs(th) (Max) @ Id 4V @ 8mA
Input Capacitance (Ciss) (Max) @ Vds 9000pF @ 25V
Current - Continuous Drain (Id) @ 25°C 150A Tc
Gate Charge (Qg) (Max) @ Vgs 360nC @ 10V
Rise Time 60ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 60 ns
Turn-Off Delay Time 100 ns
Continuous Drain Current (ID) 150A
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 100V
Pulsed Drain Current-Max (IDM) 560A
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
