IXFA36N30P3
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 300V 36A TO-263AA
PDF
/
Buying Options
Total Price: USD $4.56
Unit Price: USD $4.5584
≥1 USD $4.5584
≥10 USD $3.612752
≥100 USD $3.096632
≥500 USD $2.75257
≥1000 USD $2.356895
≥3000 USD $2.219272
Inventory: 112
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2014
Series HiPerFET?, Polar3?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Power Dissipation-Max 347W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 110m Ω @ 18A, 10V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2040pF @ 25V
Current - Continuous Drain (Id) @ 25°C 36A Tc
Gate Charge (Qg) (Max) @ Vgs 30nC @ 10V
Drain to Source Voltage (Vdss) 300V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Continuous Drain Current (ID) 36A
Compliance
RoHS Status ROHS3 Compliant
