IXFA102N15T
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 150V 102A D2PAK
PDF
/
Inventory: 9065
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Published 2009
Series HiPerFET?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish PURE TIN
Additional Feature AVALANCHE RATED
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max 455W Tc
Operating Mode ENHANCEMENT MODE
Case Connection DRAIN
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 18m Ω @ 500mA, 10V
Vgs(th) (Max) @ Id 5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds 5220pF @ 25V
Current - Continuous Drain (Id) @ 25°C 102A Tc
Gate Charge (Qg) (Max) @ Vgs 87nC @ 10V
Drain to Source Voltage (Vdss) 150V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Continuous Drain Current (ID) 102A
JEDEC-95 Code TO-263AA
Drain-source On Resistance-Max 0.018Ohm
Pulsed Drain Current-Max (IDM) 300A
DS Breakdown Voltage-Min 150V
Avalanche Energy Rating (Eas) 750 mJ
Compliance
RoHS Status ROHS3 Compliant
