SPP08N80C3XK
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 800V 8A TO-220AB
PDF
/
Inventory: 7074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Avalanche Energy Rating (Eas) 340 mJ
DS Breakdown Voltage-Min 800V
Pulsed Drain Current-Max (IDM) 24A
Drain-source On Resistance-Max 0.65Ohm
Drain Current-Max (Abs) (ID) 8A
JEDEC-95 Code TO-220AB
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 800V
Gate Charge (Qg) (Max) @ Vgs 60nC @ 10V
Current - Continuous Drain (Id) @ 25°C 8A Tc
Input Capacitance (Ciss) (Max) @ Vds 1100pF @ 100V
Vgs(th) (Max) @ Id 3.9V @ 470μA
Rds On (Max) @ Id, Vgs 650m Ω @ 5.1A, 10V
FET Type N-Channel
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 104W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE RATED, HIGH VOLTAGE
Terminal Finish Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series CoolMOS?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
