SPD09P06PL
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 60V 9.7A DPAK
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.41515
≥1 USD $0.41515
≥10 USD $0.34105
≥100 USD $0.32965
≥500 USD $0.3192
≥1000 USD $0.30875
Inventory: 1128
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 70 mJ
Pulsed Drain Current-Max (IDM) 38.8A
Drain to Source Breakdown Voltage -60V
Drain-source On Resistance-Max 0.25Ohm
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 9.7A
Turn-Off Delay Time 49 ns
Fall Time (Typ) 89 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 60V
Rise Time 168 ns
Gate Charge (Qg) (Max) @ Vgs 21nC @ 10V
Current - Continuous Drain (Id) @ 25°C 9.7A Tc
Input Capacitance (Ciss) (Max) @ Vds 450pF @ 25V
Vgs(th) (Max) @ Id 2V @ 250μA
Rds On (Max) @ Id, Vgs 250m Ω @ 6.8A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Case Connection DRAIN
Power Dissipation 42W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 42W Tc
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating -9.7A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Voltage - Rated DC -60V
Subcategory Other Transistors
Additional Feature AVALANCHE RATED, LOGIC LEVEL COMPATIBLE
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Series SIPMOS?
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
