Package Super D2-Pak
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description MOSFET N-CH 40V 185A SUPER D2PAK
PDF
/
Inventory: 1556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Vgs (Max) ±16V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 40V
Gate Charge (Qg) (Max) @ Vgs 140nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 185A Tc
Input Capacitance (Ciss) (Max) @ Vds 7660pF @ 25V
Vgs(th) (Max) @ Id 1V @ 250μA
Rds On (Max) @ Id, Vgs 4.5mOhm @ 110A, 10V
FET Type N-Channel
Power Dissipation-Max 300W Tc
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series HEXFET?
Packaging Tube

Physical

Supplier Device Package SUPER D2-PAK
Package / Case Super D2-Pak
Mounting Type Surface Mount
