IRL1104SPBF
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 104A D2PAK
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.52095
≥1 USD $1.52095
≥10 USD $1.2483
≥100 USD $1.20935
≥500 USD $1.1704
≥1000 USD $1.13145
Inventory: 1330
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 9.65mm
Length 10.67mm
Height 4.83mm
Technical
Nominal Vgs 1 V
Rds On Max 8 mΩ
Drain to Source Resistance 12mOhm
Recovery Time 126 ns
Input Capacitance 3.445nF
Dual Supply Voltage 40V
Drain to Source Breakdown Voltage 40V
Gate to Source Voltage (Vgs) 16V
Threshold Voltage 1V
Continuous Drain Current (ID) 104A
Turn-Off Delay Time 32 ns
Fall Time (Typ) 64 ns
Vgs (Max) ±16V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 40V
Rise Time 257ns
Gate Charge (Qg) (Max) @ Vgs 68nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 104A Tc
Input Capacitance (Ciss) (Max) @ Vds 3445pF @ 25V
Vgs(th) (Max) @ Id 1V @ 250μA
Rds On (Max) @ Id, Vgs 8mOhm @ 62A, 10V
FET Type N-Channel
Turn On Delay Time 18 ns
Power Dissipation 2.4W
Element Configuration Single
Power Dissipation-Max 2.4W Ta 167W Tc
Current Rating 104A
Technology MOSFET (Metal Oxide)
Voltage - Rated DC 40V
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series HEXFET?
Published 2004
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Supplier Device Package D2PAK
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
