IRFS7530-7PPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-263-7, D2Pak (6 Leads + Tab)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N CH 60V 240A D2PAK
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
Inventory: 1521
Minimum: 1
-
+
Technical Details
Technical
Drive Voltage (Max Rds On,Min Rds On) 6V 10V
Vgs (Max) ±20V
Fall Time (Typ) 79 ns
Turn-Off Delay Time 168 ns
Continuous Drain Current (ID) 240A
Threshold Voltage 3.7V
Gate to Source Voltage (Vgs) 3.7V
Drain to Source Voltage (Vdss) 60V
Rise Time 102ns
Gate Charge (Qg) (Max) @ Vgs 354nC @ 10V
Current - Continuous Drain (Id) @ 25°C 240A Tc
Input Capacitance (Ciss) (Max) @ Vds 12960pF @ 25V
Vgs(th) (Max) @ Id 3.7V @ 250μA
Rds On (Max) @ Id, Vgs 1.4m Ω @ 100A, 10V
FET Type N-Channel
Turn On Delay Time 24 ns
Power Dissipation 375W
Power Dissipation-Max 375W Tc
Number of Channels 1
Configuration Single
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Series HEXFET?, StrongIRFET?
Published 2008
Packaging Tube
Operating Temperature -55°C~175°C TJ
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 1.59999g
Number of Pins 7
Package / Case TO-263-7, D2Pak (6 Leads + Tab)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
