IRF9520NPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
INFINEON IRF9520NPBF MOSFET Transistor, P Channel, 6.8 A, -100 V, 480 mohm, -10 V, -4 V
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.779
≥1 USD $0.779
≥10 USD $0.63935
≥100 USD $0.6194
≥500 USD $0.59945
≥1000 USD $0.5795
≥3000 USD $0.51965
Inventory: 1502
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.69mm
Length 10.54mm
Height 15.24mm
Technical
Nominal Vgs -4 V
Recovery Time 150 ns
Dual Supply Voltage -100V
Pulsed Drain Current-Max (IDM) 27A
Drain to Source Breakdown Voltage -100V
Gate to Source Voltage (Vgs) 20V
JEDEC-95 Code TO-220AB
Threshold Voltage -4V
Continuous Drain Current (ID) -6.8A
Turn-Off Delay Time 28 ns
Fall Time (Typ) 31 ns
Drain to Source Voltage (Vdss) 100V
Rise Time 47 ns
Gate Charge (Qg) (Max) @ Vgs 27nC @ 10V
Current - Continuous Drain (Id) @ 25°C 6.8A Tc
Input Capacitance (Ciss) (Max) @ Vds 350pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 480m Ω @ 4A, 10V
Transistor Application SWITCHING
FET Type P-Channel
Turn On Delay Time 14 ns
Case Connection DRAIN
Power Dissipation 48W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Number of Elements 1
Lead Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 30
Current Rating -6.8A
Peak Reflow Temperature (Cel) 250
Technology MOSFET (Metal Oxide)
Max Power Dissipation 48W
Voltage - Rated DC -100V
Subcategory Other Transistors
Additional Feature AVALANCHE RATED, HIGH RELIABILITY
Min Operating Temperature -55°C
Max Operating Temperature 175°C
Resistance 480mOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series HEXFET?
Published 1998
Packaging Tube
Physical
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 12 Weeks
Alternative Model
