IRF7494PBF
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 150V 5.2A 8-SOIC
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 5200
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Supplier Device Package 8-SO
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2008
Series HEXFET?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 44MOhm
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Technology MOSFET (Metal Oxide)
Number of Elements 1
Power Dissipation-Max 2.5W Ta
Power Dissipation 3W
Turn On Delay Time 9 ns
FET Type N-Channel
Rds On (Max) @ Id, Vgs 44mOhm @ 3.1A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1783pF @ 25V
Current - Continuous Drain (Id) @ 25°C 5.1A Ta
Gate Charge (Qg) (Max) @ Vgs 53nC @ 10V
Rise Time 10ns
Drain to Source Voltage (Vdss) 150V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 14 ns
Turn-Off Delay Time 29 ns
Continuous Drain Current (ID) 5.2A
Threshold Voltage 4V
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage 150V
Dual Supply Voltage 150V
Input Capacitance 1.75nF
Drain to Source Resistance 44mOhm
Rds On Max 44 mΩ
Nominal Vgs 4 V
Dimensions
Height 1.4986mm
Length 4.9784mm
Width 3.9878mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
