IRF7207
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 20V 5.4A 8-SOIC
PDF
/
Buying Options
Total Price: USD $11.61
Unit Price: USD $11.6109
≥1 USD $11.6109
≥10 USD $9.52755
≥100 USD $9.22925
≥500 USD $8.9319
≥1000 USD $8.6336
Inventory: 1087
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2000
Series HEXFET?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature AVALANCHE RATED, HIGH RELIABILITY
Subcategory Other Transistors
Technology MOSFET (Metal Oxide)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G8
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Power Dissipation-Max 2.5W Tc
Operating Mode ENHANCEMENT MODE
FET Type P-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 60m Ω @ 5.4A, 4.5V
Vgs(th) (Max) @ Id 700mV @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 780pF @ 15V
Current - Continuous Drain (Id) @ 25°C 5.4A Tc
Gate Charge (Qg) (Max) @ Vgs 22nC @ 4.5V
Drain to Source Voltage (Vdss) 20V
Drive Voltage (Max Rds On,Min Rds On) 2.7V 4.5V
Vgs (Max) ±12V
JEDEC-95 Code MS-012AA
Drain Current-Max (Abs) (ID) 5.4A
Drain-source On Resistance-Max 0.06Ohm
Pulsed Drain Current-Max (IDM) 43A
DS Breakdown Voltage-Min 20V
Avalanche Energy Rating (Eas) 140 mJ
Compliance
RoHS Status Non-RoHS Compliant
