IRF4905STRLPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 55V 42A D2PAK
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 174421
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Transistor Element Material SILICON
Manufacturer Package Identifier D2Pak
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 1997
Series HEXFET?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Resistance 20mOhm
Additional Feature HIGH RELIABILITY, AVALANCHE RATED
Subcategory Other Transistors
Voltage - Rated DC -55V
Technology MOSFET (Metal Oxide)
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating -74A
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PSSO-G2
Number of Elements 1
Number of Channels 1
Power Dissipation-Max 170W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 3.8W
Case Connection DRAIN
Turn On Delay Time 20 ns
FET Type P-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 20m Ω @ 42A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 3500pF @ 25V
Current - Continuous Drain (Id) @ 25°C 42A Tc
Gate Charge (Qg) (Max) @ Vgs 180nC @ 10V
Rise Time 99 ns
Drain to Source Voltage (Vdss) 55V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 64 ns
Turn-Off Delay Time 51 ns
Continuous Drain Current (ID) -42A
Threshold Voltage -2V
Gate to Source Voltage (Vgs) 20V
Drain to Source Breakdown Voltage -55V
Pulsed Drain Current-Max (IDM) 280A
Dual Supply Voltage -55V
Recovery Time 92 ns
Max Junction Temperature (Tj) 150°C
Nominal Vgs -4 V
Dimensions
Height 4.83mm
Length 10.54mm
Width 10.54mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
