IRF2805STRRPBF
RoHS
/
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 55V 135A D2PAK
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.35755
≥1 USD $1.35755
≥10 USD $1.11435
≥100 USD $1.0792
≥500 USD $1.04405
≥1000 USD $1.00985
Inventory: 1176
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Published 2010
Series HEXFET?
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Power Dissipation-Max 200W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 4.7m Ω @ 104A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 5110pF @ 25V
Current - Continuous Drain (Id) @ 25°C 135A Tc
Gate Charge (Qg) (Max) @ Vgs 230nC @ 10V
Drain to Source Voltage (Vdss) 55V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
