IPB65R310CFDATMA2
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
LOW POWER_LEGACY
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $1.98176
≥100 USD $1.577312
≥500 USD $1.334678
Inventory: 1000
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 650V
Gate Charge (Qg) (Max) @ Vgs 41nC @ 10V
Current - Continuous Drain (Id) @ 25°C 11.4A Tc
Input Capacitance (Ciss) (Max) @ Vds 1100pF @ 100V
Vgs(th) (Max) @ Id 4.5V @ 400μA
Rds On (Max) @ Id, Vgs 310m Ω @ 4.4A, 10V
FET Type N-Channel
Power Dissipation-Max 104.2W Tc
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CoolMOS? CFD2
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
