BSO110N03MSGXUMA1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 30V 10A 8-Pin DSO T/R
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 14052
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Avalanche Energy Rating (Eas) 20 mJ
Max Dual Supply Voltage 30V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 10A
Turn-Off Delay Time 9.5 ns
Fall Time (Typ) 4.4 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Rise Time 4.4ns
Gate Charge (Qg) (Max) @ Vgs 20nC @ 10V
Current - Continuous Drain (Id) @ 25°C 10A Ta
Input Capacitance (Ciss) (Max) @ Vds 1500pF @ 15V
Halogen Free Halogen Free
Vgs(th) (Max) @ Id 2V @ 250μA
Rds On (Max) @ Id, Vgs 11m Ω @ 12.1A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 7.8 ns
Power Dissipation 1.56W
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 1.56W Ta
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Terminal Form GULL WING
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE RATED
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series OptiMOS?
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 18 Weeks
