AUIRFU8401
RoHS
RoHS compliant
RoHS compliantPackage TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 100A IPAK
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
Inventory: 1217
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Number of Pins 3
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Published 2013
Series HEXFET?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Number of Channels 1
Power Dissipation-Max 79W Tc
Element Configuration Single
Power Dissipation 79W
Turn On Delay Time 7.9 ns
FET Type N-Channel
Rds On (Max) @ Id, Vgs 4.25m Ω @ 60A, 10V
Vgs(th) (Max) @ Id 3.9V @ 500μA
Input Capacitance (Ciss) (Max) @ Vds 2200pF @ 25V
Current - Continuous Drain (Id) @ 25°C 100A Tc
Gate Charge (Qg) (Max) @ Vgs 63nC @ 10V
Rise Time 34ns
Drain to Source Voltage (Vdss) 40V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±20V
Fall Time (Typ) 24 ns
Turn-Off Delay Time 25 ns
Continuous Drain Current (ID) 100A
Gate to Source Voltage (Vgs) 20V
Dimensions
Height 6.22mm
Length 6.73mm
Width 2.39mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
