EPC2001
RoHS
RoHS compliant
RoHS compliantPackage Die
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
TRANS GAN 100V 25A BUMPED DIE
PDF
/
Inventory: 2947
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Die
Supplier Device Package Die Outline (11-Solder Bar)
Technical
Operating Temperature -40°C~125°C TJ
Packaging Cut Tape (CT)
Published 2011
Series eGaN?
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology GaNFET (Gallium Nitride)
FET Type N-Channel
Rds On (Max) @ Id, Vgs 7mOhm @ 25A, 5V
Vgs(th) (Max) @ Id 2.5V @ 5mA
Input Capacitance (Ciss) (Max) @ Vds 950pF @ 50V
Current - Continuous Drain (Id) @ 25°C 25A Ta
Gate Charge (Qg) (Max) @ Vgs 10nC @ 5V
Drain to Source Voltage (Vdss) 100V
Drive Voltage (Max Rds On,Min Rds On) 5V
Vgs (Max) +6V, -5V
Continuous Drain Current (ID) 25A
Input Capacitance 950pF
Rds On Max 7 mΩ
Compliance
RoHS Status ROHS3 Compliant
