RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 25V 50A TO252
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.11115
≥1 USD $0.11115
≥10 USD $0.0912
≥100 USD $0.08835
≥500 USD $0.0855
≥1000 USD $0.08265
≥10000 USD $0.0741
Inventory: 1121
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Published 2008
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Power Dissipation-Max 3W Ta 50W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 6m Ω @ 30A, 10V
Vgs(th) (Max) @ Id 3V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 2220pF @ 12.5V
Current - Continuous Drain (Id) @ 25°C 50A Tc
Gate Charge (Qg) (Max) @ Vgs 38nC @ 10V
Drain to Source Voltage (Vdss) 25V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Vgs (Max) ±20V
Continuous Drain Current (ID) 50A
Compliance
RoHS Status RoHS Compliant
