RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 30V 20A 8-Pin SOIC
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.43208
≥100 USD $0.300432
≥500 USD $0.234555
≥1000 USD $0.190643
Inventory: 7490
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Compliance
RoHS Status ROHS3 Compliant
Technical
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 20A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Drain to Source Voltage (Vdss) 30V
Gate Charge (Qg) (Max) @ Vgs 22.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 20A Ta
Input Capacitance (Ciss) (Max) @ Vds 951pF @ 15V
Vgs(th) (Max) @ Id 2.2V @ 250μA
Rds On (Max) @ Id, Vgs 5.8m Ω @ 20A, 10V
FET Type N-Channel
Power Dissipation 3.1W
Power Dissipation-Max 3.1W Ta
Number of Elements 1
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011
Packaging Digi-Reel?
Operating Temperature -55°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
