SD57060
RoHS
RoHS compliant
RoHS compliantPackage M243
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - RF
Description
FET RF 65V 945MHZ M243
PDF
/
Buying Options
Total Price: USD $68.06
Unit Price: USD $68.0599
≥1 USD $68.0599
≥10 USD $65.93285
≥100 USD $63.80675
≥500 USD $61.6797
≥1000 USD $55.29855
Inventory: 1146
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 8 months ago)
Physical
Mount Screw
Package / Case M243
Number of Pins 243
Technical
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Subcategory FET General Purpose Power
Voltage - Rated DC 65V
Max Power Dissipation 108W
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Current Rating 7A
Frequency 945MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number SD57060
Pin Count 3
JESD-30 Code R-PDFM-F2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 108W
Case Connection SOURCE
Current - Test 100mA
Transistor Application AMPLIFIER
Drain to Source Voltage (Vdss) 65V
Polarity/Channel Type N-CHANNEL
Transistor Type LDMOS
Continuous Drain Current (ID) 7A
Gate to Source Voltage (Vgs) 20V
Gain 15dB
Max Output Power 60W
Drain Current-Max (Abs) (ID) 7A
Drain to Source Breakdown Voltage 65V
Input Capacitance 88pF
FET Technology METAL-OXIDE SEMICONDUCTOR
Voltage - Test 28V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
