PD57006S-E
RoHS
RoHS compliant
RoHS compliantPackage PowerSO-10 Exposed Bottom Pad
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - RF
Description
FET RF 65V 945MHZ PWRSO-10
PDF
/
Inventory: 9334
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case PowerSO-10 Exposed Bottom Pad
Number of Pins 4
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish MATTE TIN
Max Operating Temperature 165°C
Min Operating Temperature -65°C
Subcategory FET General Purpose Power
Max Power Dissipation 20W
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 250
Current Rating 1A
Frequency 945MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number PD57006
Pin Count 10
JESD-30 Code R-PDSO-F2
Number of Elements 1
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 20W
Case Connection SOURCE
Current - Test 70mA
Transistor Application AMPLIFIER
Drain to Source Voltage (Vdss) 65V
Polarity/Channel Type N-CHANNEL
Transistor Type LDMOS
Continuous Drain Current (ID) 1A
Gate to Source Voltage (Vgs) 20V
Max Output Power 6W
Drain Current-Max (Abs) (ID) 1A
Drain to Source Breakdown Voltage 65V
FET Technology METAL-OXIDE SEMICONDUCTOR
Voltage - Test 28V
Min Breakdown Voltage 65V
Power Gain 15dB
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
