LET9045C
RoHS
RoHS compliant
RoHS compliantPackage M243
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - RF
Description
MOSFET N-CH 80V 9A M-250
PDF
/
Buying Options
Total Price: USD $19.36
Unit Price: USD $19.3553
≥1 USD $19.3553
≥10 USD $15.88115
≥100 USD $15.38525
≥500 USD $14.8884
≥1000 USD $14.3925
Inventory: 1623
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 32 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Screw
Package / Case M243
Number of Pins 3
Technical
Packaging Tray
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Subcategory FET General Purpose Power
Max Power Dissipation 108W
Terminal Position DUAL
Terminal Form FLAT
Current Rating 9A
Frequency 960MHz
Base Part Number LET9045
Pin Count 2
JESD-30 Code R-PDFM-F2
Number of Elements 1
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Case Connection SOURCE
Current - Test 300mA
Transistor Application AMPLIFIER
Drain to Source Voltage (Vdss) 80V
Polarity/Channel Type N-CHANNEL
Transistor Type LDMOS
Continuous Drain Current (ID) 9A
Gate to Source Voltage (Vgs) 15V
Gain 17.7dB
Drain Current-Max (Abs) (ID) 9A
Power - Output 59W
FET Technology METAL-OXIDE SEMICONDUCTOR
Voltage - Test 28V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
