VEC2616-TL-H
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, Flat Lead
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Description
Trans MOSFET N/P-CH 60V 3A/2.5A 8-Pin VEC T/R
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.3458
≥1 USD $0.3458
≥10 USD $0.28405
≥100 USD $0.2755
≥500 USD $0.266
≥1000 USD $0.25745
Inventory: 247
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2.3mm
Length 2.9mm
Height 750μm
Technical
FET Feature Logic Level Gate
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 2.5A
Turn-Off Delay Time 65 ns
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 10nC @ 10V
Current - Continuous Drain (Id) @ 25°C 3A 2.5A
Input Capacitance (Ciss) (Max) @ Vds 505pF @ 20V
Vgs(th) (Max) @ Id 2.6V @ 1mA
Rds On (Max) @ Id, Vgs 80m Ω @ 1.5A, 10V
FET Type N and P-Channel
Power Dissipation 1W
Element Configuration Dual
Number of Elements 2
Pin Count 8
Max Power Dissipation 1W
Terminal Finish Tin/Bismuth (Sn/Bi)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e6
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Number of Pins 8
Package / Case 8-SMD, Flat Lead
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE, NOT REC (Last Updated: 1 week ago)
