NDS8947
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Description
Tape & Reel (TR) Surface Mount 2P-Channel (Dual) Dual Mosfet Array 4A -4A 900mW 19ns
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
Inventory: 6969
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Weight 230.4mg
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Resistance 65mOhm
Voltage - Rated DC -30V
Max Power Dissipation 900mW
Terminal Form GULL WING
Current Rating -4A
Number of Elements 2
Row Spacing 6.3 mm
Element Configuration Dual
Operating Mode ENHANCEMENT MODE
Power Dissipation 2W
Turn On Delay Time 9 ns
FET Type 2 P-Channel (Dual)
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 65m Ω @ 4A, 10V
Vgs(th) (Max) @ Id 2.8V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 690pF @ 15V
Current - Continuous Drain (Id) @ 25°C 4A
Gate Charge (Qg) (Max) @ Vgs 30nC @ 10V
Rise Time 20ns
Drain to Source Voltage (Vdss) 30V
Fall Time (Typ) 19 ns
Turn-Off Delay Time 40 ns
Continuous Drain Current (ID) -4A
Threshold Voltage -1.6V
Gate to Source Voltage (Vgs) 20V
Drain Current-Max (Abs) (ID) 4A
Drain to Source Breakdown Voltage -30V
Dual Supply Voltage -30V
FET Technology METAL-OXIDE SEMICONDUCTOR
FET Feature Logic Level Gate
Nominal Vgs -1.6 V
Dimensions
Width 4.05mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
