MMDF3N04HDR2
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Description
MOSFET 2N-CH 40V 3.4A 8-SOIC
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.41515
≥1 USD $0.41515
≥10 USD $0.34105
≥100 USD $0.32965
≥500 USD $0.3192
≥1000 USD $0.30875
Inventory: 1092
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Feedback Cap-Max (Crss) 96 pF
FET Feature Logic Level Gate
FET Technology METAL-OXIDE SEMICONDUCTOR
Drain to Source Breakdown Voltage 40V
Drain Current-Max (Abs) (ID) 3.4A
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 3A
Turn-Off Delay Time 15 ns
Fall Time (Typ) 19 ns
Rise Time 15 ns
Gate Charge (Qg) (Max) @ Vgs 28nC @ 10V
Current - Continuous Drain (Id) @ 25°C 3.4A
Input Capacitance (Ciss) (Max) @ Vds 900pF @ 32V
Vgs(th) (Max) @ Id 3V @ 250μA
Rds On (Max) @ Id, Vgs 80m Ω @ 3.4A, 10V
Transistor Application SWITCHING
FET Type 2 N-Channel (Dual)
Power Dissipation 2W
Operating Mode ENHANCEMENT MODE
Configuration SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE
Number of Elements 2
Qualification Status Not Qualified
Pin Count 8
Base Part Number MMDF3N04HD
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 3A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Max Power Dissipation 1.39W
Voltage - Rated DC 40V
Subcategory FET General Purpose Power
Additional Feature LOGIC LEVEL COMPATIBLE, AVALANCHE ENERGY RATED
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2006
Packaging Cut Tape (CT)
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 weeks ago)
