FDC6320C
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6 Thin, TSOT-23-6
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Description
MOSFET N/P-CH 25V SSOT6
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
Inventory: 271653
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6 Thin, TSOT-23-6
Number of Pins 6
Weight 36mg
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 1997
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination SMD/SMT
ECCN Code EAR99
Resistance 4Ohm
Terminal Finish Tin (Sn)
Additional Feature LOGIC LEVEL COMPATIBLE
Subcategory Other Transistors
Max Power Dissipation 700mW
Terminal Form GULL WING
Current Rating 220mA
Number of Elements 2
Element Configuration Dual
Operating Mode ENHANCEMENT MODE
Power Dissipation 900mW
FET Type N and P-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 4 Ω @ 400mA, 4.5V
Vgs(th) (Max) @ Id 1.5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 9.5pF @ 10V
Current - Continuous Drain (Id) @ 25°C 220mA 120mA
Gate Charge (Qg) (Max) @ Vgs 0.4nC @ 4.5V
Rise Time 6 ns
Polarity/Channel Type N-CHANNEL AND P-CHANNEL
Fall Time (Typ) 6 ns
Turn-Off Delay Time 7.4 ns
Continuous Drain Current (ID) 220mA
Threshold Voltage 850mV
Gate to Source Voltage (Vgs) 8V
Drain to Source Breakdown Voltage 25V
Dual Supply Voltage 25V
FET Technology METAL-OXIDE SEMICONDUCTOR
FET Feature Logic Level Gate
Nominal Vgs 850 mV
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
