IRF7380PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Description
HEXFET? Tube Surface Mount 2N-Channel (Dual) Mosfet Array 3.6A 2W 80V -55C~150C TJ
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.65835
≥1 USD $0.65835
≥10 USD $0.54055
≥100 USD $0.52345
≥500 USD $0.50635
≥1000 USD $0.48925
Inventory: 117599
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2008
Series HEXFET?
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Base Part Number IRF7380PBF
Power - Max 2W
FET Type 2 N-Channel (Dual)
Rds On (Max) @ Id, Vgs 73m Ω @ 2.2A, 10V
Vgs(th) (Max) @ Id 4V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 660pF @ 25V
Current - Continuous Drain (Id) @ 25°C 3.6A
Gate Charge (Qg) (Max) @ Vgs 23nC @ 10V
Drain to Source Voltage (Vdss) 80V
FET Feature Logic Level Gate
Compliance
RoHS Status ROHS3 Compliant
