TIP32C
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 100V 3A TO-220
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.2728
≥1 USD $0.2728
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 4.535924g
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC -100V
Max Power Dissipation 40W
Current Rating -3A
Base Part Number TIP32
Pin Count 3
Number of Elements 1
Polarity PNP, NPN
Element Configuration Single
Power Dissipation 2W
Transistor Application SWITCHING
Gain Bandwidth Product 3MHz
Transistor Type PNP
Collector Emitter Voltage (VCEO) -100V
Max Collector Current -3A
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 3A 4V
Current - Collector Cutoff (Max) 300μA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 1.2V @ 375mA, 3A
Collector Emitter Breakdown Voltage 100V
Current - Collector (Ic) (Max) 3A
Transition Frequency 3MHz
Collector Emitter Saturation Voltage -1.2V
Collector Base Voltage (VCBO) -100V
Emitter Base Voltage (VEBO) -5V
hFE Min 10
Max Junction Temperature (Tj) 150°C
Dimensions
Height 19.68mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
