TIP107
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP DARL 100V 8A TO-220
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.8712
≥1 USD $0.8712
≥10 USD $0.70312
≥100 USD $0.557128
≥500 USD $0.472243
≥1000 USD $0.384692
≥3000 USD $0.362146
Inventory: 780
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 6.000006g
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Transistors
Voltage - Rated DC -100V
Max Power Dissipation 80W
Current Rating -8A
Base Part Number TIP107
Pin Count 3
Number of Elements 1
Polarity PNP
Element Configuration Single
Power Dissipation 2W
Transistor Application SWITCHING
Transistor Type PNP - Darlington
Collector Emitter Voltage (VCEO) 100V
Max Collector Current 8A
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 3A 4V
Current - Collector Cutoff (Max) 50μA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 2.5V @ 80mA, 8A
Collector Emitter Breakdown Voltage 100V
Collector Emitter Saturation Voltage 2V
Collector Base Voltage (VCBO) 100V
Emitter Base Voltage (VEBO) 5V
hFE Min 200
Dimensions
Height 9.15mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
