STW2040
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT NPN 500V 20A 3-Pin(3+Tab) TO-247 Tube
PDF
/
Inventory: 8568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Transistors
Max Power Dissipation 125W
Base Part Number STW2040
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 125W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 500V
Max Collector Current 20A
DC Current Gain (hFE) (Min) @ Ic, Vce 15 @ 6A 5V
Current - Collector Cutoff (Max) 250μA
Vce Saturation (Max) @ Ib, Ic 500mV @ 1.2A, 6A
Collector Emitter Breakdown Voltage 500V
Emitter Base Voltage (VEBO) 9V
hFE Min 21
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
