STT13005
RoHS
RoHS compliant
RoHS compliantPackage TO-225AA, TO-126-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT NPN 400V 2A 3-Pin(3+Tab) SOT-32 Tube
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2869
≥1 USD $0.2869
≥10 USD $0.2356
≥100 USD $0.228
≥500 USD $0.2204
≥1000 USD $0.2128
Inventory: 1188
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-225AA, TO-126-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Transistors
Max Power Dissipation 45W
Base Part Number STT13
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 45W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 400V
Max Collector Current 2A
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 500mA 5V
Current - Collector Cutoff (Max) 250μA
Vce Saturation (Max) @ Ib, Ic 1.5V @ 400mA, 1.6A
Collector Emitter Breakdown Voltage 400V
Emitter Base Voltage (VEBO) 9V
hFE Min 10
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
