STL73D
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 400V 1.5A TO-92
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
≥10 USD $0.22264
≥100 USD $0.1848
≥500 USD $0.169101
≥1000 USD $0.163504
Inventory: 3355
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Technical
Packaging Bulk
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Subcategory Other Transistors
Max Power Dissipation 1.5W
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STL73
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Power Dissipation 1.5W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 400V
Max Collector Current 1.5A
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 600mA 3V
Vce Saturation (Max) @ Ib, Ic 1V @ 250mA, 1A
Collector Emitter Breakdown Voltage 400V
Emitter Base Voltage (VEBO) 18V
hFE Min 10
Turn Off Time-Max (toff) 4700ns
Compliance
RoHS Status ROHS3 Compliant
