STD826T4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
STMICROELECTRONICS STD826T4 Bipolar (BJT) Single Transistor, PNP, 60 V, 100 MHz, 15 W, 3 A, 100 hFE
PDF
/
Buying Options
Total Price: USD $3.25
Unit Price: USD $3.2528
≥1 USD $3.2528
≥10 USD $2.66855
≥100 USD $2.5859
≥500 USD $2.5023
≥1000 USD $2.4187
Inventory: 1265
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Saturation Current 3A
hFE Min 100
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 60V
Max Breakdown Voltage 30V
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 30V
Vce Saturation (Max) @ Ib, Ic 1.1V @ 150mA, 3A
Current - Collector Cutoff (Max) 100μA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 2V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 30V
Transistor Type PNP
Polarity/Channel Type PNP
Transistor Application SWITCHING
Power Dissipation 15W
Configuration SINGLE
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STD826
Time@Peak Reflow Temperature-Max (s) 30
Frequency 100MHz
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Max Power Dissipation 15W
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Cut Tape (CT)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
