STD724T4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 30V 3A DPAK
PDF
/
Buying Options
Total Price: USD $9
Unit Price: USD $8.996537
≥1 USD $8.996537
≥10 USD $8.487299
≥100 USD $8.006882
≥500 USD $7.553664
≥1000 USD $7.1261
Inventory: 1502
Minimum: 1
-
+
Technical Details
Technical
Power Dissipation 15W
Transistor Application SWITCHING
Gain Bandwidth Product 100MHz
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 30V
Max Collector Current 3A
DC Current Gain (hFE) (Min) @ Ic, Vce 80 @ 1A 2V
Current - Collector Cutoff (Max) 100μA
Vce Saturation (Max) @ Ib, Ic 1.1V @ 150mA, 3A
Collector Emitter Breakdown Voltage 30V
Transition Frequency 100MHz
Collector Emitter Saturation Voltage 1.1V
Max Breakdown Voltage 30V
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 5V
hFE Min 100
Saturation Current 3A
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STD724
Time@Peak Reflow Temperature-Max (s) 30
Frequency 100MHz
Current Rating 3A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Max Power Dissipation 15W
Voltage - Rated DC 30V
Subcategory Other Transistors
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
