STD1802T4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
STMICROELECTRONICS - STD1802T4 - Bipolarer Einzeltransistor (BJT), Universal, NPN, 60 V, 150 MHz, 15 W, 3 A, 200 hFE
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6864
≥1 USD $0.6864
≥10 USD $0.594
≥100 USD $0.4114
≥500 USD $0.34371
≥1000 USD $0.292521
Inventory: 12908
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Cut Tape (CT)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Transistors
Max Power Dissipation 15W
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Frequency 150MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STD18
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 1
Configuration SINGLE
Power Dissipation 15W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 3A
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 100mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 400mV @ 150mA, 3A
Collector Emitter Breakdown Voltage 60V
Transition Frequency 150MHz
Max Breakdown Voltage 60V
Collector Base Voltage (VCBO) 80V
Emitter Base Voltage (VEBO) 6V
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
