STBV68
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistors - BJT Hi Vltg FAST SWITCH NPN Pwr TRANSISTOR
PDF
/
Inventory: 4727
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC 400V
Max Power Dissipation 900mW
Terminal Position BOTTOM
Current Rating 600mA
Base Part Number STBV68
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 900mW
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 400V
Max Collector Current 600mA
DC Current Gain (hFE) (Min) @ Ic, Vce 3 @ 250mA 10V
Vce Saturation (Max) @ Ib, Ic 5V @ 100mA, 250mA
Collector Emitter Breakdown Voltage 400V
Collector Base Voltage (VCBO) 600V
Emitter Base Voltage (VEBO) 9V
hFE Min 7
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
