STBV32G-AP
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 400V 1.5A TO-92AP
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.4884
≥100 USD $0.33968
≥500 USD $0.265232
Inventory: 925
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Emitter Base Voltage (VEBO) 9V
Max Breakdown Voltage 400V
Collector Emitter Breakdown Voltage 400V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 500mA, 1.5A
Current - Collector Cutoff (Max) 1mA
DC Current Gain (hFE) (Min) @ Ic, Vce 5 @ 1A 2V
Max Collector Current 1.5A
Collector Emitter Voltage (VCEO) 400V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power - Max 1.5W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number STBV32
Terminal Position BOTTOM
Max Power Dissipation 1.5W
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Box (TB)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
