ST1802HI
RoHS
RoHS compliant
RoHS compliantPackage ISOWATT-218-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 600V 10A ISOWATT218
PDF
/
Inventory: 5748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
hFE Min 4
Emitter Base Voltage (VEBO) 7V
Collector Base Voltage (VCBO) 1.5kV
Collector Emitter Breakdown Voltage 600V
Vce Saturation (Max) @ Ib, Ic 5V @ 800mA, 4A
Current - Collector Cutoff (Max) 1mA
DC Current Gain (hFE) (Min) @ Ic, Vce 4 @ 5A 5V
Max Collector Current 10A
Collector Emitter Voltage (VCEO) 5V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Case Connection ISOLATED
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number ST1802
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 10A
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 50W
Voltage - Rated DC 600V
Subcategory Other Transistors
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Package / Case ISOWATT-218-3
Mounting Type Through Hole
Mount Through Hole
