PN2222A
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 40V 0.6A TO-92
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1387
≥1 USD $0.1387
≥10 USD $0.114
≥100 USD $0.1102
≥500 USD $0.1064
≥1000 USD $0.10355
≥5000 USD $0.09215
Inventory: 1449
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Turn Off Time-Max (toff) 285ns
hFE Min 100
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 75V
Transition Frequency 270MHz
Collector Emitter Breakdown Voltage 40V
Vce Saturation (Max) @ Ib, Ic 1V @ 50mA, 500mA
Current - Collector Cutoff (Max) 10nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 10V
Max Collector Current 600mA
Collector Emitter Voltage (VCEO) 40V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 270MHz
Transistor Application SWITCHING
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number PN2222
Current Rating 600mA
Terminal Position BOTTOM
Max Power Dissipation 500mW
Voltage - Rated DC 40V
Subcategory Other Transistors
HTS Code 8541.21.00.75
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
