MMBT2907A
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount PNP Single Bipolar (BJT) Transistor 100 @ 150mA 10V 10nA ICBO 350mW 200MHz
PDF
/
Buying Options
Total Price: USD $0.01
Unit Price: USD $0.007585
≥1 USD $0.007585
≥10 USD $0.006054
≥100 USD $0.005204
≥500 USD $0.004694
≥1000 USD $0.0152
≥10000 USD $0.01425
Inventory: 1336
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Turn On Time-Max (ton) 45ns
hFE Min 100
Emitter Base Voltage (VEBO) -5V
Collector Base Voltage (VCBO) -60V
Max Breakdown Voltage 60V
Transition Frequency 200MHz
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 1.6V @ 50mA, 500mA
Current - Collector Cutoff (Max) 10nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 10V
Max Collector Current 600mA
Collector Emitter Voltage (VCEO) 60V
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 200MHz
Transistor Application SWITCHING
Power Dissipation 350mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number MMBT
Current Rating -800mA
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 350mW
Voltage - Rated DC -60V
Subcategory Other Transistors
HTS Code 8541.21.00.75
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
