MJD31CT4-A
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 100V 3A DPAK
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9328
≥1 USD $0.9328
≥10 USD $0.76384
≥100 USD $0.594088
≥500 USD $0.503571
≥1000 USD $0.410212
Inventory: 2933
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 100V
Max Breakdown Voltage 100V
Collector Emitter Breakdown Voltage 100V
Vce Saturation (Max) @ Ib, Ic 1.2V @ 375mA, 3A
Current - Collector Cutoff (Max) 50μA
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 3A 4V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 100V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Case Connection COLLECTOR
Power Dissipation 15W
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number MJD31
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Max Power Dissipation 15W
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 8 Weeks
