MJD127T4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount PNP - Darlington Single Bipolar (BJT) Transistor 1000 @ 4A 4V 10muA 20W 100V
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.57728
≥100 USD $0.399784
≥500 USD $0.33403
≥1000 USD $0.284275
Inventory: 2245
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Weight 1.799996g
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Transistors
Voltage - Rated DC -100V
Max Power Dissipation 20W
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating -5A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MJD127
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 1
Polarity PNP
Element Configuration Single
Power Dissipation 20W
Case Connection COLLECTOR
Transistor Application SWITCHING
Transistor Type PNP - Darlington
Collector Emitter Voltage (VCEO) 100V
Max Collector Current 8A
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 4A 4V
Current - Collector Cutoff (Max) 10μA
Vce Saturation (Max) @ Ib, Ic 4V @ 80mA, 8A
Collector Emitter Breakdown Voltage 100V
Collector Emitter Saturation Voltage 4V
Max Breakdown Voltage 100V
Collector Base Voltage (VCBO) 100V
Emitter Base Voltage (VEBO) 5V
hFE Min 1000
Max Junction Temperature (Tj) 150°C
VCEsat-Max 4 V
Dimensions
Height 2.63mm
Length 6.6mm
Width 6.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
