MJB44H11T4
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 80V 10A D2PAK-3
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 5347
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Continuous Collector Current 10A
hFE Min 60
Emitter Base Voltage (VEBO) 5V
Max Breakdown Voltage 80V
Max Frequency 50MHz
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 1V @ 400mA, 8A
Current - Collector Cutoff (Max) 10μA
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 4A 1V
Max Collector Current 10A
Collector Emitter Voltage (VCEO) 80V
Transistor Type NPN
Polarity/Channel Type NPN
Power Dissipation 50W
Element Configuration Single
Number of Elements 1
Base Part Number MJB44
Max Power Dissipation 50W
Subcategory Other Transistors
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Cut Tape (CT)
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
